Termékismertető
RB951Ui-2HnD
The RB951Ui-2HnD is a wireless SOHO AP with a new generation Atheros CPU and more processing power. It has five Ethernet ports, one USB 2.0 port and a high power 2.4GHz 1000mW 802.11b/g/n wireless AP with antennas built in.
It has a 600MHz CPU,128MB of RAM and PoE output function for port #5 - it can power other PoE capable devices with the same voltage as applied
to the unit. Maximum load on the port is 500mA.
Package contains RouterBOARD 951Ui-2HnD in a plastic case and power adapter.
Product specifications
| Details | |
|---|---|
| Product code | RB951Ui-2HnD |
| CPU nominal frequency | 600 MHz |
| CPU core count | 1 |
| Size of RAM | 128 MB |
| 10/100 Ethernet ports | 5 |
| 10/100/1000 Ethernet ports | 0 |
| MiniPCI slots | 0 |
| MiniPCI-e slots | 0 |
| Wireless chip model | AR9344-DC3A |
| Wireless standards | 802.11b/g/n |
| Number of USB ports | 1 |
| Power Jack | 1 |
| 802.3af support | No |
| Supported input voltage | 7 V - 31 V |
| PoE in | Yes |
| PoE out | Yes |
| Voltage Monitor | No |
| CPU temperature monitor | No |
| PCB temperature monitor | No |
| Dimensions | 113x138x29mm |
| Operating System | RouterOS |
| Operating temperature range | -20C +50C |
| License level | 4 |
| Antenna gain DBI | 2.5 |
| Current Monitor | No |
| CPU | AR9344-DC3A |
| Max Power consumption | Up to 7W |
| SFP ports | 0 |
| SFP+ ports | 0 |
| USB slot type | USB type A |
| Number of chains | 2 |
| Serial port | None |
Wireless specifications
| 2.4 GHz | ||
|---|---|---|
| TX | RX | |
| 6MBit/s | 30 | -96 |
| 54MBit/s | 25 | -80 |
| MCS0 | 30 | -96 |
| MCS7 | 23 | -78 |
wireless parameters may be limited in software, depending on your local regulatory limitations
Letölthető fájlok, adatlapok
| RB951Ui-2HnD Datasheet.pdf |
